Dobot CR7A bridges the gap between the lightweight CR5A and the larger CR10A, delivering a 7 kg payload and 800 mm reach in a compact 24.5 kg platform at 3 m/s TCP speed. With ±0.02 mm repeatability and the same EtherCAT-driven joint architecture delivering 223°/s, the CR7A is engineered for tasks demanding higher force and torque than the CR5A can provide without expanding the footprint to the full CR10A form factor. It shares all of the CRA series' safety, programming, and ecosystem features, including DobotStudio Pro and optional SafeSkin pre-collision sensing.
Key Highlights
- 7 kg payload; 800 mm reach; 24.5 kg; 3 m/s TCP speed
- ±0.02 mm repeatability; EtherCAT joints at 223°/s
- 22 built-in safety features; ISO 13849 and TS15066 certified
- IP54 protection; 48V DC; 150W power consumption
- DobotStudio Pro; drag-to-teach; 20+ development platform support
- Bridges CR5A and CR10A for medium-payload compact applications
